Foxeer Digisight V2 Nano FPV Camera 720P Digital Analog Low Latency Super WDR
Specification:
- Sensor Type: S0ny 1/3" CMOS Sensor
- Scale: 4:3(default)/16:9 Switchable
- Tv System: PAL(default)/NTSC Switchable
- Resolution: Digital 720P/Analog 1000TVL
- Shutter Speed: PAL 1/25~1/10000 sec; NTSC 1/30~1/10000 sec
- Video Output: 720P Digital HD/CVBS Analog Signal
- FOV Digital: FOV-H:120° FOV-D: 145°
- Analog: FOV-H:125° FOV-D: 155°
- Shutter Speed: Auto
- Minimum Illumination: 0.01Lux
- White Balance: Auto
- DNR: 3DNR 2DNR
- WDR: 120dB
- Mode: DAY/CLOUDY/Night/LED
- Fast Mode Switch: Long Press Right Button to switch among DAY/CLOUDY/Night/LED
- Flight OSD: Cam Title / Voltage (Only in analog) / Time
- Input Power
- Digital: 3.3V from VTx
- Analog: 4.5~20V
- Language: ENGLISH/ DEUTSCH/ FRANCAIS/ PYCCKNN/ PORTUGUES/ ESPANOL/ 中文
- Working Temperature: -10°~50°C RH90% MAX
- Working Humidity: 20~80%
- Storage Temperature: -20°~70°C
- Menu: Analog via camera programming board, Digital via VTx programming board
- Consumption
- Analog:50mA±15% @ DC12V 115mA±15% @ DC5V
- Digital:350mA@3.3V(Powered by VTX)
- Dimension: 14*14mm; 19*19mm(Add Bracket)
- Weight: 4.3g(Exclude cable)
- 1x Foxeer DigiSight V2 Nano
- 4x (M2x4)Screws
- 4x Bracket Ring
- 4x (M2x6) Bracket Screws
- 1x OSD Board
- 1x Bracket
- 1x 2pin OSD Cable
- 1x Ribbon Cable
- 1x Servo Cable
